TP-LINK 14-Slot Media Converter Rackmount Chassis, 19" 2U, 2 x Cooling Fans, PSU

14-Slot Rackmount Chassis

TL-MC1400

14 bays to house up to 14 media converters
Optional redundant power supply to ensure non-stop reliable operation
Hot-Swappable; easy & quick replacement of converter and power supply
Mounted two cooling fans for better ventilation

What This Product Does

The TL-MC1400 14-Slot Rack-mount Chassis is specially designed to accommodate 14 TP-LINK‘s Media Converters for central power supply, saving space and power cables. Continuous operation is of great importance to fiber communication, so the chassis is equipped with optional redundant power supply and Hot-Swapping function which allows installing/removing the converter/power supply without powering off the chassis. Moreover, to stabilize the performance and extend the lifetime, two cooling fans are installed internally. Together with MC series Gigabit / Fast Ethernet media converters, TL-MC1400 is the ideal solution for your media conversion network.

* For TP-LINK Media Converters, TL-MC1400 supports MCXXX ver:2.0 and above, not ver:1.0.”

Type	Media Converter Rackmount Chassis
Enclosure Type	Rackmount
Basic Functions	14 bays to house up to 14 media converters Hot-Swappable Power isolation for elec isolation from each bay
Dimensions (WxDxH)	482 x 358 x 86 mm Standard 19-Inch, 2U height
Power Supply	Input: 100-240V~50/60Hz 3.0A(Max) Output:+9.5VDC, 9.5A(Max) Vripple: <50mv Noise: <100mv
Environment (℃)	Operating Temperature: 0C~40C (32F~104F) Storage Temperature: -40C~70C (-40F~158F) Operating Humidity: 10%~90% non-condensing Storage Humidity:5%~90% non-condensing
Package Type	Retail
Package Weight	6.7000 kg
Warranty	Limited Lifetime

Manufacturer	TP-LINK
Color	No
Connectivity	Wired
Condition	Brand New
Refurbished	No
